Special Price AUTOOL C1 ELM327 V1.5 Bluetooth/WIFI OBD2/OBD II Auto Car Diagnostic Scanner Tool With PIC18F25K80 Chip For Android/IOS

No Comments

Special Price AUTOOL C1 ELM327 V1.5 Bluetooth/WIFI OBD2/OBD II Auto Car Diagnostic Scanner Tool With PIC18F25K80 Chip For Android/IOS

Special Price AUTOOL C1 ELM327 V1.5 Bluetooth/WIFI OBD2/OBD II Auto Car Diagnostic Scanner Tool With PIC18F25K80 Chip For Android/IOS

Product ID : 32827023481
Price : $12.00 – 13.00
Discount Price : $11.28 – 12.22

VISIT WEBSITE NOW

Item specifics
  • Item Width:
    4cm
  • Item Type:
    Other
  • Power:
    W
  • Brand Name:
    AUTOOL
  • External Testing Certification:
    CE
  • Electronic:
    No
  • Voltage:
    12V
  • Model Name:
    C1
  • Special Features:
    Bluetooth
  • Material Type:
    TOP
  • Hardware Version:
    PIC18F25K80 Chip V1.5
  • Item Length:
    5cm
  • Software Version:
    V2.1
  • Item Height:
    5cm
  • Item Weight:
    0.1kg
  • OBDII decode chip:
    ARM 16bit MCU
  • Compare with other ELM327 protocol :
    Support J1939 protocol more than ELM327
  • Compare with other ELM327 power consump:
    Lower power consumption than ELM327
  • warranty:
    3 years warranty
Product Description







1



  • Fully compatible with ELM327 V1.4b, all ELM327 supported software are available to use
  • Four times faster than ELM327.(ELM327 is RISC 8bit 44MHz MCU, iCar is ARM 16bit MCU)
  • Support J1939 protocol more than ELM327
  • Sleep Mode, Lower power consumption than ELM327
  • WiFi 802.11 b/g or 802.11n module
  • Supports more protocols SAE J1850 than V2.1
  • Firmware Version V1.5 (With chip:PIC18F25K80,supports all elm327 fucntions,in program ELM327 identifier,it shows full function

Specifications
1. OBDII decode chip: ARM 16bit MCU
2. Firmware: ELM327 Version 1.4b compatible
3. Transfer baud rate: 4800 / 9600 / 10400 / 38400 (default) / 115200 / 500K
4. Input interface: OBDII male 16pin
5. Output interface: Wifi 802.11 b/g or 802.11n after 2013 Feb 01
6. LED Indicator: Power(red) / OBD(green) / Link(blue) (PC or smart phone)
7. Operating Voltage: 12V from car OBD2 socket, including over voltage /shortage protection
8. Nominal Idle current: 45mA
9.Communication range: 500m open field
10.SSID: VGATE (discontinued) or BUYOBD (current)
11.Encryption: Open (VGATE) and WEP shared/WEP128 (BUYOBD)



Please confirm OBDII label located under front engine hood.
Support OBDII/EOBD2 protocols:
ISO 15765-4 (CAN-B 125Kbps, started since 2003 in USA)
ISO 15765-4 (CAN-C 500Kbs, 11bit ID, 29bit ID, started since 2003 in USA)
ISO 14230-4 (KWP2000)
ISO 9141-2 (5 baud init. 10.4 kbaud, replaced by 14230-4 gradually, stopped in USA in 2008)
SAE J1850 VPW (10.4 kbaud, replaced by 14230-4 gradually, stopped in USA in 2008)
SAE J1850 PWM (41.6 kbaud, replaced by 14230-4 gradually, stopped in USA in 2008)
SAE J1939 the Data link connector standard


Support Various Vehicles:

This elm327 usually can work on most new car with OBD 16pin Aadapter and 12V engine:
For USA Car brand,after 1996;
For Europe Car brand(petrol),after 2001;
For Europe Car brand(diesel),after 2004;
For Japan/Korea Car brand,after 2002;
For Chinese Car brand,after 2009;
For Indian Car brand,after 2010;
For  Russian Car brand,after 2011;


Note:If you are not sure whether it compatible with your car, please do not hesitate to contact us first



Please look under the hood and try to locate a label(like the picture)that explicitly states that the vehicle was designed to comply with OBD-II legislation.



HTB1.Q7EPFXXXXXZXFXXq6xXFXXXD












sdse

C1_01C1_02C1_03C1_04C1_05

HTB1Aaj7RXXXXXXiaXXXq6xXFXXXk


HTB1zgx0SFXXXXb2XXXXq6xXFXXXj

HTB1AlNXSFXXXXavaFXXq6xXFXXXJ


HTB10WERKVXXXXcuXpXXq6xXFXXXF

HTB1_IUYKVXXXXcGXXXXq6xXFXXX1
HTB1q8UWKVXXXXcRXXXXq6xXFXXX4
HTB1R5.xKVXXXXXpapXXq6xXFXXXk
HTB1ofb.NVXXXXaXapXXq6xXFXXXQ












Packaging Details
  • Unit Type:
    piece
  • Package Weight:
    0.05kg (0.11lb.)
  • Package Size:
    5cm x 4cm x 3cm (1.97in x 1.57in x 1.18in)
