Wireless Mini Data Collector Handheld Barcode Scanner Reader Laser Bar Code POS Terminal -NT9800mini
Operating system.:RADALL inventory system
CPU count: single core
CPU frequency: 72MHz
Keyboard type: T9 numeric keypad
Power:2800mAh lithium battery(Rechargeable)
Material:ABS + silicone
Working current: 160mA
Standby current: 8mA
Light source type: red laser diode, wavelength 650nm
Scan mode: Single line scan
Scanning speed: 48 ± 2 times per second
Scanning accuracy: 3mil
Scan width: 20mm window, 220mm 200mm
Scanning depth of field: 0 ~ 250mm (0.33mm, PCS 90%)
Bit error rate: 1/5 million
Prompt mode: buzzer, LCD direct display
Decoding capability: EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, Codaber, Industoal 2 of 5, Interleave 2 of 5, Matrix 2 of 5 and MSI.
ROM:16MB (can save more than 100,000 product information)
Memory card type: not supported
Wireless data transmission using 433M wireless data transmission technology, with wireless transmission, automatic storage, automatic retransmission, data screen display and other functions, two-way communication, 99 wireless channels, each channel can support up to 255 collector. Can be more than a fat collection, you can also send a multi-collection, the same location can be set at the same time using multiple wireless collector without disturbing each other. Wireless transmission of data automatically check the check function to ensure that the collector and the host computer between the reliable wireless data transmission. Data acquisition and computer connections do not need to install any driver software, upload data directly simple, very convenient.
The data collection can be widely used in commercial and retail management; logistics; drug supervision; food regulation; library management; publications management; mail management; blood bank management; warehouse management; enterprise fixed assets management; banking, insurance; Railway; military; public security and other fields; industrial control; catering a la carte; hospital IC card, ordering and other fields.
