ELM327 USB V1.5 OBD2 Car Diagnostic Interface Scanner ELM 327 V 1.5 OBDII Diagnostic Tool ELM-327 OBD 2 obd2 Code Reader Scanner

Big Sale ELM327 USB V1.5 OBD2 Car Diagnostic Interface Scanner ELM 327 V 1.5 OBDII Diagnostic Tool ELM-327 OBD 2 obd2 Code Reader Scanner

Big Sale ELM327 USB V1.5 OBD2 Car Diagnostic Interface Scanner ELM 327 V 1.5 OBDII Diagnostic Tool ELM-327 OBD 2 obd2 Code Reader Scanner

Product ID : 32907798437
Price : $9.40 – 12.93
Discount Price : $7.99 – 10.99

VISIT WEBSITE NOW

Item specifics
  • Item Type:
    Code Readers & Scan Tools
  • Language:
    Polish,Korea,German,Italian,Dutch,Czech,Hungarian,Spanish,English,Turkish,French
  • Hardware Version:
    ELM327 USB V1.5 with FTDI FT232RL Chip
  • Software Version:
    ELM327 FTDI USB V1.5 ODB 2
  • Software Update:
    No
  • Brand Name:
    KONNWEI
  • Item Name:
    ELM327 USB V1.5 with FTDI FT232RL Chip
  • ELM327 FTDI USB Functions:
    Read and Erase Codes, Turn Off CHECK ENGINE LIGHT LIVE DATA
  • ELM327 OBD OBD2 Scanner Features:
    USB Communication for windows tablet/ PC, stable and faster
  • Car Makes:
    All OBD2 Compliant Vehicles
  • ELM327 FTDI USB Type:
    Auto Diagnostic Scanner
  • ELM327 FTDI USB Protocols:
    Support All OBD-II Protocols
  • ELM327 FTDI USB Version:
    ELM327 V1.5
  • ELM327 FTDI USB Compatible Device:
    Only PC Windows XP- Windows 7
  • EML327 OBD OBD2 Scanner Function:
    Check I/M Readiness, Read vehicle information
  • ELM327 USB Softwares:
    Free SCAN-MASTER ELM in CD and others

Product Description



ELM327 USB V1.5 OBD2 Car Diagnostic Interface Scanner ELM 327 V 1.5 OBDII Diagnostic Tool ELM-327 OBD 2 obd2 Code Reader Scanner



ITEM DESCRIPTION

Buyer Notice:

1. This is High-Quality USB ELM327 version, work on PC , Different with other chip ELM327 USB, It is using the ELM327 Processor, and original FTDI FT232RL Chip, builted with tough structure.
2. Our scanner is working for OBDII Compliant vehicles, real v1.5 version, supports J1850 Protocols.

FTDI FT232RL Chip

ODB-2-USB-ELM327-FTDI-With-Switch-FT232RL-Chip-V1-5-ELM-327-USB-Auto-Doagnostic.jpg_640x640 (1)

PL-2303HX Chip
ODB-2-USB-ELM327-FTDI-With-Switch-FT232RL-Chip-V1-5-ELM-327-USB-Auto-Doagnostic.jpg_640x640

HTB1TA.mRFXXXXahXFXXq6xXFXXXd
aeProduct.getSubject()
About ELM327 USB V1.5

OBD-II Software for ELM327 USB is a free program that allows you to use your PC and a hardware interface to get the information from your car's computer.
The program is very user-friendly, and easy to learn. It is also very easy to install: simply extract the files into a folder on your computer's hard drive, and you're ready to go. To uninstall the program, simply delete the entire contents of the folder where the program resides.


ELM327 OBD OBD2 Scanner  Features

ELM327 is the latest PC-based scan tool. It is dispatched with a number of compatible programs. The processor is an ELM327. The output protocol (connection to laptop) is USB.
Processor: ELM327.
OBD-II Software for ELM327 is a free program that allows you to use your PC and a hardware interface to get the information from your car's computer.
The program is very easy to install: simply extract the files into a folder on your computer's hard drive, and you're ready to go. To uninstall the program, simply delete the entire contents of the folder where the program resides.

Support 12 Languages:

English, Spanish, French, Czech, Danish, German, Croatian, Hungarian, Italian, Polish, Serbian, Turkish
aeProduct.getSubject)

ELM327  OBD OBD2 Scanner Functions

1.Read diagnostic trouble  generic  codes

2.Clear trouble codes and turn off the MIL ("Check Engine" light)

3.Display current sensor data, including:

4.Engine RPM

5.Calculated Load Value

6.Coolant Temperature

7.Fuel System Status

8.Vehicle Speed

9.Short Term Fuel Trim

10.Long Term Fuel Trim

11.Intake Manifold Pressure

12.Timing Advance

13.Intake Air Temperature

14.Air Flow Rate

15.Absolute Throttle Position

16.Oxygen sensor voltages/associated short term fuel trims

17.Fuel System status

18.Fuel Pressure

19.Many others…


Tips for free softwares:
OBD Gauge for PalmOS and Pocket PC by Dana Peters
OBD Logger by Jonathan Senkerik
OBD-II ScanMaster by Wladimir Gurskij (ScanMaster 3.52 – local copy)
obd2crazy.com
OBD2 Scantool by Ivan Andrewjeski
OBDII for ELM322 by David Huffman
pyOBD by Donour Sizemore for MacOSX and Linux
RDDTC by Pete Calinski
Real Scan by Brent Harris
ScanTest for Pocket PC by Ivan Ganev aka a-ser
wOBD by WDT

With our ELM327 (EML327), you will be able to perform a complete computer diagnostics of your car   and even to correct minor faults without resorting to service stations.

Our scan tool is a high-quality automotive scanning tool, supports all OBD-II Protocols :

0.Automatic
1.SAE J1850 PWM(41.6Kbaud)
2.SAE J1850 VPW(10.4Kbaud)
3.ISO9141-2(5 baud init,10.4Kbaud)
4.ISO14230-4 KWP(5 baud init,10.4 Kbaud)
5.ISO14230-4 KWP(fast init,10.4 Kbaud)
6.ISO15765-4 CAN(11bit ID,500 Kbaud)
7.ISO15765-4 CAN(29bit ID,500 Kbaud)
8.ISO15765-4 CAN(11bit ID,250 Kbaud)
9.ISO15765-4 CAN(29bit ID,250 Kbaud)
A.SAE J1939 CAN(29bit ID,250*Kbaud)
B.USER1 CAN(11*bit ID,125*Kbaud)
C.USER2 CAN(11*bit ID,50*kbaud)
*default settings(user adjustable)

Delivery time Note:    If your Confirmation Time is coming, you still not receive the goods, please contact us, we will extend the delivery date in advance.

No Dispute please:   Please do not apply dispute within 60 days, let's keep good business relationship. Thanks for your kind understanding.


SOFTWARE DISPLAY

aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()
aeProduct.getSubject()


ITEM PICTURES

aeProduct.getSubject()

4 (3)6 (2)

KONNWEI ITEM FAQ

Below are Q&A related to using questions

Q1: Does elm327 usb support diesel car ?
A1: This elm327 USB support for Diesel car, doesn't support truck

Q2: Does elm327 support my car?
The device support your car or not based on whether your car has obd2 protocol or not.

What is obd2 protocol ?

OBD2 is car communication protocol, which was adopted as part of a government to detect vehicle exhaust emissions
American car support obd2 after 1996 year
European car support obd2 after 2004 year
Asian car support obd2 protocol after 2008, Some Japanese car support after 2005
​If you have any questions, please don't heasitate to contact us!

PACKING LIST

1pc x USB Type ELM327 For PC

1pc x CD drive with free softwares
(If you received the broken CD, please contact us right away, we will send you a link for download, the full version ScanMaster-ELM we will send you a link for download)





Packaging Details
  • Unit Type:
    piece
  • Package Weight:
    0.13kg (0.29lb.)
  • Package Size:
    15cm x 12cm x 4cm (5.91in x 4.72in x 1.57in)
